    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home

    Ask Lasest Price
    Brand Name : Lekol
    Model Number : LQM3W116E
    Certification : CE
    Price :
    Payment Terms : T/T
    Supply Ability : 50000PCS per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home

    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home


    With the growing number of electric vehicles (EVs), which are in some markets becoming viable alternatives to traditional internal combustion engine vehicles , the demand for enhanced semiconductor solutions for charging stations increases too.

    Lekol offers a complete solution for residential, commercial and public plug-in electric vehicle charging: the Lekol line of electrical vehicle supply equipment and accessories . Our Lekol products are compliant with all industry standards and compatible with all major auto manufacturers’ electric vehicles ( SAE J1772 TM compliant).


    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home


    LQM3W116E Model Feature:


    1. MODBUS TCP applicable via RS485 interface
    2. OCPP 1.6J
    3. RCD-TYPE B
    4. APP control
    5. 4.3 inch HD human-machine interface(HMI).
    6. CE certified
    7. Load balancing solving proposal
    8. OEM services and quick turnaround


    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home

    3.5kw 16A Plug And Play Public Electric Charging Points Ev Fast Charger For Home


    Specification

    Charging Connector/ plug type
    IEC62196-2 /Type 2
    SAEJ1772 /Type 1
    AC Power input rating
    1 phase 220V±15%
    3 phase
    380V±15%
    AC Level 2
    240V
    AC Power Output Rating
    3.5KW /16A
    11KW /16A
    3.5KW/16A
    7KW/32A
    22KW/32A
    7KW/32A
    N/A

    43KW/63A
    10KW.40A
    Rated Frequency
    50/60HZ
    User interface & control
    Charging control
    Plug and charge √
    RFID card √
    CMS operate √
    Display Screen
    4.3inch LCD screen
    Wifi connection
    Support √
    OCPP Protocol
    1.6J √
    2.0.1 √
    Ethernet Interface
    LANE(RJ-45) √
    APP interface
    Support √

    Environmental
    Storage Temperature
    -40 ~ 75℃
    Operating Temperature
    -30 ~ 55℃
    Operating Humidity
    Up tp 95%, non-condensing
    Altitude
    ≤2000m
    Cooling Method
    Natural Cooling
    Protection
    Over Voltage Protection
    Under Voltage Protection
    Over Load Protection
    Short Circuit Protection
    Earth Leakage Protection
    Ground Protection
    Over-temp Protection
    Surge Protection
    RCD
    RCCB or Type B
    Protection ratings
    IP54 ( CE certified)
    Wallbox Charger Mechanical
    Dimension(H×W×D,mm)
    410×260×164
    Weight
    1 phase :9kg 3 phase:12kg
    Charging Cable Length
    5m or 7.5m or customized
    Enclosure Material
    Front-panel: Tempered Glass, Back-cover: Plate Metal
    LQM3T Mounting Pole(Optional)
    Dimension(H×W×D,mm)
    1400×200×100
    Weight
    <8kg
    Enclosure Material
    Metal

    Why choose lekol?


    1. Experienced technical team

    2. Strict factory inspection

    3. Excellent after-sales service
